Motorola NAG4000A antenna

Frequency Range: UHF (403-512 MHz)
Type: Mobile fiberglass antenna
Length: Approximately 36 inches (91.4 cm)
Power Handling: Up to 100 watts
Impedance: 50 ohms
VSWR: ≤1.5:1 (typical within operating band)
Gain: ~6.0 dBi
Connector Type: N-type female
Material: Fiberglass radome with copper coil element
Compatibility: Designed for Motorola UHF mobile 2-way radios, ideal for fixed-site or vehicle-mounted high-gain applications in public safety, utilities, and large-area coverage networks

product details

product description

Function Introduction

UHF 403–512 MHz Optimization

Tuned for this critical band, maximizing signal clarity and propagation for 2 Way Radios in urban, rural, and industrial environments. This precision minimizes interference, outperforming lower-gain options for Radio Walkie Talkie users needing reliable long-distance connectivity.

NAG4000A High-Gain Design

With 6.0 dBi gain and a 36-inch fiberglass structure, it delivers exceptional range for 2 Way Radios— critical for emergency services, utility fleets, and remote operations. This performance surpasses standard whip antennas, eliminating dead zones in vital Radio Walkie Talkie communications across large areas.

100W Power Handling

Supports high-output 2 Way Radios, maintaining stability during prolonged, high-demand use. This durability prevents signal drop-offs, a key advantage for Radio Walkie Talkie operations in 24/7 emergency response or utility management.

Product Parameters

Dimension	36 inches (91.4 cm)
Frequency Range	UHF (403-512 MHz)
Type	Mobile fiberglass antenna
Power Handling	Up to 100 watts
Impedance	50 ohms
VSWR	≤1.5:1
Gain	~6.0 dBi
Connector Type	N-type female
