Motorola HAE6022 Antenna

Frequency Range: UHF (450-470 MHz)
Type: Portable stubby antenna
Length: Approximately 2.2 inches (5.59 cm)
Power Handling: Up to 5W
Impedance: 50 ohms
VSWR: ≤2.0:1 (typical)
Gain: ~1.0 dBi
Connector Type: SMA male
Material: Flexible rubber casing with internal metal core
Compatibility: Designed for Motorola APX series radios (e.g., APX 6000, APX 8000)

product details

product description

Function Introduction

UHF 450–470 MHz Tuning

Optimized for this critical band, ensuring clear transmission for 2 Way Radios in urban or confined spaces. This precision minimizes interference, surpassing multi-band Radio Walkie Talkie antennas in crowded frequencies.

HAE6022 Compact Design

At 2.2 inches (5.59 cm), it’s perfect for 2 Way Radios users needing unobtrusive gear— ideal for first responders or staff moving through tight spaces. This sleek profile reduces snagging risks compared to longer Radio Walkie Talkie antennas.

APX Series Compatibility

Designed for Motorola APX 6000/8000 2 Way Radios, featuring a secure SMA fit that avoids signal loss common with ill-fitting Radio Walkie Talkie antennas— vital for mission-critical coordination.

Product Parameters

Dimension	2.2 inches (5.59 cm)
Frequency Range	UHF (450-470 MHz)
Type	Portable stubby antenna
Power Handling	Up to 5W
Impedance	50 ohms
VSWR	≤2.0:1 (typical)
Gain	~1.0 dBi
Connector Type	SMA male
