Motorola HAE4011 antenna

Frequency Range: VHF (136-174 MHz)
Type: Portable stubby antenna
Length: Approximately 2.75 inches (6.99 cm)
Power Handling: Up to 5W
Impedance: 50 ohms
VSWR: ≤2.0:1 (typical)
Gain: ~1.5 dBi
Connector Type: BNC male
Material: Flexible rubber casing with internal metal core
Compatibility: Designed for Motorola XTS series radios

product details

product description

Function Introduction

VHF 136–174 MHz Tuning

Optimized for this critical band, ensuring reliable transmission for 2 Way Radios in urban or indoor settings. This precision surpasses multi-band Radio Walkie Talkie antennas, minimizing interference in crowded frequencies.

HAE4011 Compact Design

At 2.75 inches (6.99 cm), it’s perfect for 2 Way Radios users needing unobtrusive gear— ideal for first responders or staff moving through tight spaces. This sleek profile reduces snagging risks compared to longer Radio Walkie Talkie antennas.

XTS Series Compatibility

Designed for Motorola XTS2500, XTS3000, and similar 2 Way Radios, ensuring a secure BNC fit and consistent performance. This versatility avoids signal loss common with ill-fitting Radio Walkie Talkie antennas, preserving communication integrity.

Product Parameters

Dimension	2.75 inches (6.99 cm)
Frequency Range	VHF (136-174 MHz)
Type	Portable stubby antenna
Power Handling	Up to 5W
Impedance	50 ohms
VSWR	≤2.0:1 (typical)
Gain	~1.5 dBi
Connector Type	BNC male
