Motorola DP1400 Entry-level Walkie Talkie

  • Frequency Range:
    • VHF: 136–174 MHz.
    • UHF: 403–470 MHz.
  • Output Power:
    • Low Power: VHF 1W, UHF 1W.
    • High Power: VHF 5W, UHF 4W.
  • Channel Capacity: 32 channels.
  • Channel Spacing: 12.5 kHz/20 kHz/25 kHz.
  • Frequency Stability: ±0.5 ppm.
  • Battery Capacity:
    • NiMH 1400 mAh.
    • Slim Li-Ion 1600 mAh.
    • High Cap Li-Ion 2250 mAh.
    • Ultra-High Cap Li-Ion 2900 mAh.
  • Battery Life:
    • NiMH 1400mAh: Analog 9.5 hours, Digital 12 hours.
    • Slim Li-Ion 1600mAh: Analog 15 hours, Digital 19.5 hours.
    • High Cap Li-Ion 2250mAh: Analog 19.5 hours, Digital 25 hours.
  • Dimensions (H×W×D):
    • NiMH 1400mAh: 128×62×42 mm.
    • Slim Li-Ion 1600mAh: 128×62×39 mm.
    • High Cap Li-Ion 2250mAh: 128×62×44 mm.
    • Ultra-High Cap Li-Ion 2900mAh: 128×62×44 mm.
  • Weight:
    • NiMH 1400mAh: 406g.
    • Slim Li-Ion 1600mAh: 341g.
    • High Cap Li-Ion 2250mAh: 346g.
    • Ultra-High Cap Li-Ion 2900mAh: 348g.
  • Display: No display.
  • Audio Features: Equipped with advanced noise-cancellation technology (SINC+) to filter background noise, ensuring clear voice transmission.
  • Durability: Meets MIL-STD-810 standards and passes Motorola's unique Accelerated Life Test (ALT).
  • Environmental Adaptability: IP54-rated, dustproof and water-resistant.
  • Audio Output: Maximum voice loudness of 98 phon at 30 cm.
  • Receiver Sensitivity:
    • Analog: 0.3 µV/0.22 µV (typical).
    • Digital (5% BER): 2.25 µV/0.19 µV (typical)
  • Digital Voice Encoder: AMBE+2.
  • Digital Protocol: ETSI TS 102 361-1, -2, -3
    Contact us Download
    product details
    Product Detail Diagram

    Frequency range

    VHF (136-174 MHz); UHF (403-470 MHz)

    Power

    Power supply- 7.5V (Nominal)

    Battery life (based on a 05 05 90 duty cycle)

    NiMH (1400mAh) Battery

    Analogue: 9 hours Digital : 11.5 hours

    Li-Ion Slim (1600 mAH) Battery Analogue: 10.5 hours Digital : 13.5 hours High Cap Li-ion (2200 mAH) Battery Analogue: 14.5 hours Digital: 18.5 hours

    Audio output

    0.5 W (Internal)

    Rotary on off volume

    Yes

    Tri-colour status LED

    Yes

    Emergency button

    Programmable

    Keypad

    None

    Display

    No Display

    Weight (with standard battery)

    406g (NiMH 1400mAH) 341 g (Slim Li-Ion 1600mAH) 346 g (Li-Ion 2200mAH)

    Dimensions H x W x D (with standard battery)

    127.7 X 61.5 X 42.0 mm (NiMH 1400mAH) 127.7 X 61.5 X 39.0 mm (Slim Li-Ion 1600mAH) 127.7 X 61.5 X 44.0 mm (Li-Ion 2200mAH)

    Programmable buttons

    Yes

    Voice operated transmit (VOX)

    Yes

    Time out timer

    Yes

    Talkaround

    Yes

    Signalling

    MDC/QCII/Digital

    Scrambling

    Built-in

    Scan types

    Normal, Priority, Dual priority, Nuisance channel delete, Talk group, All group

    Selective calling

    Yes

    Digital Private Line

    Yes

    Private Line

    Yes

    Monitor Permanent (Sticky) Monitor

    Yes

    CPS (Customer Programming Software)

    Yes

    Channel spacing (kHz)

    12.5, 25, 20, 12.5 (6.25 efficient)

    Number of channels

    16

    Channel scan

    Yes

    Call tones

    Yes

    Busy channel lockout

    Yes

    Audio gain control

    Yes

    Integrated voice and data

    Yes

    Advanced Software Features

    Remote Monitor

    System type

    Conventional, TDMA

    Digital technology

    Yes

    Noise reduction software

    Yes

    Submersible

    Yes

    Accelerated life test

    Yes

    Mil spec

    810 C, 810 D, 810 E, 810 F, 810 G

    IP Standards

    IP54

    Standard warranty

    2 years

    Function Introduction

    DP1400(750X750)-(2)ne1
    about   DP1400

    The Motorola Solutions DP1400 is an entry-level walkie talkie that provides all the features you want to use on more advanced devices. The DP1400 is a type of MOTTRBO walkie talkie series, characterized by good sound quality, wide coverage, and long battery life.
    DP1400 (2)0an
    about   DP1400

    DP1400 features 32 channels that allow you to establish clearer communication for different employees. The ergonomic design of this mobile phone allows users to operate all control devices while wearing gloves, while the two configurable buttons and various accessories provide users with many options.
    DP1400(750X750) (13)tr1
    about   DP1400

    DP1400 is your lifeline in critical communication, which means it must be built for the toughest situations. Motorola Solutions conducted MIL-STD-810 testing on DP1400 to ensure it was designed for work. In addition to standard testing, we also perform our unique Accelerated Life Test (ALT), so you can be confident that your walkie talkie can be used on-site for many years.
    DP1400 (1)v5d
    about   DP1400

    No matter what your needs are, DP1400 can provide you with a simple, reliable, and low-cost communication system, allowing your work team to connect, coordinate, collaborate, and do a good job. The DP1400 adopts the most advanced analog and digital bidirectional radio technology, making it an ideal choice for daily communication with the outside world.
