DMR Mobile Vehicle 25W Radio Motorola XIR M3188
product detail
1. Features
The rugged MOTOTRBO XiR M3188 and XiR M3688 are available as analog/digital mobile radios that offer all the benefits of the latest technology – from superior audio to greater coverage. These affordable performers are compatible with advanced MOTOTRBO features you’ll find are business-essential, for example a transmission can be interrupted to prioritize critical communications.
With its bright, high contrast alphanumeric screen, the XiR M3688 allows drivers to see important information such as caller Id at a glance. The XiR M3188 offers lower capacity and a simpler numeric display.
The XiR M3188 and XiR M3688 are so easy to use and deliver such clear voice communications, you’ll be amazed how efficient your operation can be.
FEATURES
• Analogue / digital
• Voice Communications
• Canned Text Message
• dual Capacity direct Mode
• Transmit Interrupt (decode only)
• Voice announcement
• Numeric display (XiR M3188)
• Digital Mobile Radio (DMR) Standards Compliant
• IP54 Rated
OPTIONS • Radio Management Suite
2. Specifications
General Specifications | |
Frequency Range |
VHF:136MHz-174MHz |
Memory Channel |
16 |
Channel Spacing |
12.5/20/25 kHz |
Power Output |
1 - 25W; 25 - 45W |
Power Supply |
13.2Vdc (10.8 - 15.6 Vdc) Negative Vehicle ground |
Dimensions (L×W×H) |
1.7 x 6.7 x 5.3 in (44 x 169 x 134 mm) |
Weight |
2,9 Ibs (1.3 kg) |
Communication Range |
about 10-20km |
Sealing |
IP54, MIL-STD |
Dust |
Meets MIL-STD 810-C,D&E and TIA/EIA 603 |
Transmitter Specifications | |
Channel Spacing |
12.5 kHz / 25 kHz |
Modulation Limiting |
± 2.5 kHz @ 12.5 kHz / ± 5.0 kHz @ 25 kHz |
FM Hum & Noise |
-40 dB @ 12.5 kHz / -45 dB @ 25 kHz |
Conducted/Radiated Emissions |
-36 dBm < 1 GHz / -30 dBm > 1 GHz |
Adjacent Channel Power |
60 dB @ 12.5 kHz / 70 dB @ 25 kHz |
Receiver Specifications | |
Frequency Stability |
+/- 0.5ppm |
Channel Spacing |
12.5 kHz / 25 kHz |
Intermodulation |
70 dB |
adjacent Channel Selectivity (TIa603d) |
50 dB @ 12.5 kHz 75 dB @ 20/25kHz |
Audio Response |
+ 1, -3dB |
Digital Vocoder Type |
AMBE +2™ |
Digital Protocol |
ETSI TS 102 361-1, -2, -3 |
3. Shipping
4. Payment
EEC. accept online payment method--Paypal, which takes data encryption technology to make Paypal pay safe enough, so customers no need to worry about the private infomation betraied. And Paypal is convenient for customers and sellers to trade. Seller could send Invoice first to customer for making payment. To avoid customers do not know how to make payment.
Offline payment also be accepted -- Telegraphic Transfer (TT), Western Union, MoenyGram which is convenient, reasonable, simple and Global.
