APX8000 All-bands P25 ASTRO Portable Two Way Radio
1. Features
Unlimited Mobility. Uncompromising Performance.
With four RF bands and multi-mode systemaccess, the APX 8000 knows no limits when it comes to interoperability. Whetherit’s loud or windy, whether you whisper or yell, the Adaptive Audio Engine andultra-loud speaker bring clarity into every conversation. With Wi-Fi access,the APX 8000 can quickly receive new codeplugs, firmware and software featuresin order to redeploy the radio fleet with ease as users keep talking withoutinterruption. Intuitively designed with a familiar look and feel, the compactAPX 8000 is always comfortable to use, from your grip to your holster.
KEY FEATURES
• Unlimited interoperability with one device
• Secure WiFi for seamless software updates
• Extra-large buttons for glove use
• IP68 submersion (2 meters, 4 hours)
• ANSI/ISA-12.12.01-2015 CAN/CSA C22.2 NO. 213-15, Nonincendive ElectricalEquipment for Use in Class I, Division 2, Groups A, B, C, D; Class II, Division2, Groups F, G; Class III, Division 2
• Integrated GPS/GLONASS for outdoor location tracking
• Equippedwith FIPS - certified encryption hardware
• RFID volume knob for asset tracking (optional)
• Bluetooth-enabled APX radios capable of transmitting SCBA voice and data
RF BANDS
• 700/800 MHz, VHF, UHF Range 1 & 2
OPERATION MODES
• 9600 Baud Digital APCO P25 Phase 1 FDMA and Phase 2 TDMA Trunking
• 3600 Baud SmartNet®, SmartZone®, Omnilink Trunking
• Digital APCO 25, Conventional, Analog MDC 1200, Quick Call II SystemConfigurations
• Narrow and wide bandwidth digital receiver (6.25 kHzequivalent/25/20/12.5 KHz)
STANDARD FEATURES
• Mission Critical Wireless Bluetooth*
• ASTRO 25 Integrated Voice & Data
• Integrated GPS/GLONASS for outdoor location tracking
• Software Key
• Text-Messaging
• Voice Announcements
• ISSI 8000 Roaming
• Radio Profiles, Dynamic Zone
• Intelligent Lighting
• Single-key ADP Encryption
• IP68 submersion (2 meters, 4 hours)
• IMPRES Battery
• ANSI/ISA-12.12.01-2015 CAN/CSA C22.2 NO. 213-15, Nonincendive ElectricalEquipment for Use in Class I, Division 2, Groups A, B, C, D; Class II, Division2, Groups F, G; Class III, Division
ADAPTIVE AUDIO ENGINE
• 3 Watt Speaker with Adaptive Equalization
• Adaptive Dual-sided Operation
• Adaptive Noise Suppression Intensity
• Adaptive Gain Control
• Adaptive Windporting PROGRAMMING
• Utilizes Windows 7 & 8 CustomerProgramming Software (CPS) with Radio Management OPTIONAL FEATURES
• WiFi 802.11 b/g/n
• RFID Volume Knob
• Multikey for 128 keys and multi-algorithm
• Programming Over Project 25 (OTAP)
• Over the Air Rekey (OTAR)
• Digital Tone Signaling
• P25 Authentication
• Man Down Sensor
2. Specifications
GENERAL SPECIFICATIONS | |
Channel Capacity | 3000(model 3.5) |
Frequency | 764-776, 794-806 MHz 806-825, 851-870 MHz 136-174 MHz 380-470 MHz 450-520 MHz |
FLASHport Memory | 2 GB |
Maximum Frequency Separation | Full Bandsplit |
Audio Response1 | +1, -3 dB |
Rated RF Output Power Adj1 | 700 MHz: 1-2.5 Watts ;800 MHz: 1-3 Watts ; VHF:1-6Watts; UHF:1-5Watts |
Dimensions (HxWxD) | Li-Ion IMPRES UL2054 DIV 2 Rugged 3400 mAh IP68** 3.4” x 2.3” x 1.7” |
Weight | 6.5 oz |
Display (Model 3.5) | Top display plus: Full bitmap color LCD display 4 lines of text x 14 characters 2 lines of icons 1 menu line x 3 menus White backlight |
Keypad | Backlit keypad 3 soft keys 4 direction navigation key 4x3 keypad Home and Data buttons |
RECEIVER | |
Frequency Range/Bandsplits | 764-776 MHz; 851-870 MHz; 136-174 MHz; 380-520 MHz |
Channel Spacing | 25/20/12.5 kHz |
Maximum Frequency Separation | Full Bandsplit |
Audio Output Power at Rated/Max | 3 Watt/5 Watt |
Selectivity (25 kHz / 12.5 kHz)1, 5 | 79 dB / 72 dB; 78 dB / 72 dB ;82 dB / 77 dB ;80 dB / 74 dB |
Intermodulation Rejection1 | 81 dB ;80 dB; 82 dB; 80 dB |
Audio Distortion at Rated | 1.2% ;1.3%; 1.3%; 1.2% |
Spurious Rejection1 | 98 dB ;98 dB; 92 dB; 98 dB |
ENCRYPTION | |
Supported Encryption Algorithms ADP, AES, DES, DES-XL, DES-OFB, DVP-XL, Localized Algorithm | ADP, AES, DES, DES-XL, DES-OFB, DVP-XL, Localized Algorithm |
Encryption Algorithm Capacity | 8 |
Encryption Keys per Radio | Module capable of storing 1024 keys.Programmable for 128 Common Key Reference (CKR) or 16 Physical Identifier (PID) |
GPS/GNSS SPECIFICATIONS | Constellations GPS & GLONASS |
Water and Dust Intrusion | IP68 (2 meters, 4 hours) |
TRANSMITTER | |
Frequency | 764-776, 794-806 MHz 806-825, 851-870 MHz 136-174 MHz 380-470 MHz 450-520 MHz |
Channel Spacing | 25/20/12.5 kHz |
Power Output : 700 MHz: 1-2.5 Watts 800 MHz: 1-3 Watts ; VHF: 1-6 Watts ,UHF :1-5Watts 1-6 Watts 1-5 Watts 1-6 Watts 1-5 Watts 1-5 Watts | |
